5x Cable connector - T-shape - IP68 waterproof
HOFTRONICSKU: H5435096
Product information
5x Cable connector - T-shape - IP68 waterproof
Product information
5x Cable connector - T-shape - IP68 waterproof
These waterproof cable connectors are perfect for connecting garden lights and other electrical devices in the garden. The cable connectors have a T-shape, so you can use the connectors well to go around a corner or make branches in cables. The cable connectors are IP68 waterproof. This makes your electrical installation resistant to moisture. The cable connectors are suitable for cables between 8 and 12 millimetres thick.
• IP68 waterproof
Fully protected from dust and water up to 4 meters deep. No breakdowns due to garden sprinkler, plant watering, cold, sleet, as well as tropical heat.
• Plug & play
Inside the cable connector is a crown block that allows you to connect multiple cables. You can remove the crown block to connect the cables easily.
• Suitable for installation
This version is suitable for a two or three wire cable (neutral, phase, earth). This ensures a safe connection for your garden lighting.
• 3-wire
The standard and extra caps in the cable connector are suitable for 2- and 3-wire cables. You can easily exchange them yourself for more flexibility.
• Suitable for
Waterproof T-shaped cable connector for three-core cables (neutral, phase, ground) from 8 to 12 mm thick, makes connecting light points easy.
• Black colour
The cable connector in black can be used above ground without being conspicuous. Ideal if you cannot install the cable connector in the ground.
• Seamless finish
Using the best quality rubber and plastic, this connector is the perfect solution when you want to connect cables for your garden and outdoor lighting.
• 2-year warranty
Don't worry about your cable connectors. We provide a 2-year warranty. Made with care, shipped and installed by you for worry-free use.
5x Cable connector - T-shape - IP68 waterproof
These waterproof cable connectors are perfect for connecting garden lights and other electrical devices in the garden. The cable connectors have a T-shape, so you can use the connectors well to go around a corner or make branches in cables. The cable connectors are IP68 waterproof. This makes your electrical installation resistant to moisture. The cable connectors are suitable for cables between 8 and 12 millimetres thick.
• IP68 waterproof
Fully protected from dust and water up to 4 meters deep. No breakdowns due to garden sprinkler, plant watering, cold, sleet, as well as tropical heat.
• Plug & play
Inside the cable connector is a crown block that allows you to connect multiple cables. You can remove the crown block to connect the cables easily.
• Suitable for installation
This version is suitable for a two or three wire cable (neutral, phase, earth). This ensures a safe connection for your garden lighting.
• 3-wire
The standard and extra caps in the cable connector are suitable for 2- and 3-wire cables. You can easily exchange them yourself for more flexibility.
• Suitable for
Waterproof T-shaped cable connector for three-core cables (neutral, phase, ground) from 8 to 12 mm thick, makes connecting light points easy.
• Black colour
The cable connector in black can be used above ground without being conspicuous. Ideal if you cannot install the cable connector in the ground.
• Seamless finish
Using the best quality rubber and plastic, this connector is the perfect solution when you want to connect cables for your garden and outdoor lighting.
• 2-year warranty
Don't worry about your cable connectors. We provide a 2-year warranty. Made with care, shipped and installed by you for worry-free use.
Key specifications
All specifications
Key specifications
| IP rate | IP68 |
|---|---|
| Operating-temperature | -25°C ~ 100° C |
| Number of connection points | 3 |
| Max Cable Diameter | 12 mm |
| Min Cable Diameter | 4 mm |
| Total number of clamp positions | 3 |
| Core thickness | 0.5 - 2.5 mm² |
| Max Core thickness diameter | 2.5 mm |
Key specifications
| IP rate | IP68 |
|---|---|
| Operating-temperature | -25°C ~ 100° C |
| Number of connection points | 3 |
| Max Cable Diameter | 12 mm |
| Min Cable Diameter | 4 mm |
| Total number of clamp positions | 3 |
| Core thickness | 0.5 - 2.5 mm² |
| Max Core thickness diameter | 2.5 mm |
| Min Core thickness diameter | 0.5 mm |
Color and material
| Color | Black |
|---|---|
| Material | Plastic |
Dimensions & weights
| Width | 100 mm |
|---|---|
| Height | 28 mm |
| Length | 105 mm |
General
| EAN | 8720365435096 |
|---|---|
| Brand | HOFTRONIC |
| Warranty | 2 year |
| Quantity | 5 |
| Certifications | CE, RoHs, TÜV |
| Warranty exemption | Not installed or used according to the manual |
Installation
| Ground wire | Yes |
|---|---|
| Connection voltage | 100-240V AC |
| Suitable for indoor outdoor | Indoor & outdoor |
Packaging
| Packaging type | Bag |
|---|---|
| Quantity mastercarton | 500 |
Key specifications
| IP rate | IP68 |
|---|---|
| Operating-temperature | -25°C ~ 100° C |
| Number of connection points | 3 |
| Max Cable Diameter | 12 mm |
| Min Cable Diameter | 4 mm |
| Total number of clamp positions | 3 |
| Core thickness | 0.5 - 2.5 mm² |
| Max Core thickness diameter | 2.5 mm |
Key specifications
| IP rate | IP68 |
|---|---|
| Operating-temperature | -25°C ~ 100° C |
| Number of connection points | 3 |
| Max Cable Diameter | 12 mm |
| Min Cable Diameter | 4 mm |
| Total number of clamp positions | 3 |
| Core thickness | 0.5 - 2.5 mm² |
| Max Core thickness diameter | 2.5 mm |
| Min Core thickness diameter | 0.5 mm |
Color and material
| Color | Black |
|---|---|
| Material | Plastic |
Dimensions & weights
| Width | 100 mm |
|---|---|
| Height | 28 mm |
| Length | 105 mm |
General
| EAN | 8720365435096 |
|---|---|
| Brand | HOFTRONIC |
| Warranty | 2 year |
| Quantity | 5 |
| Certifications | CE, RoHs, TÜV |
| Warranty exemption | Not installed or used according to the manual |
Installation
| Ground wire | Yes |
|---|---|
| Connection voltage | 100-240V AC |
| Suitable for indoor outdoor | Indoor & outdoor |
Packaging
| Packaging type | Bag |
|---|---|
| Quantity mastercarton | 500 |
Downloads
5x Cable connector - T-shape - IP68 waterproof
Downloads
5x Cable connector - T-shape - IP68 waterproof
Review
Key specifications
| IP rate | IP68 |
|---|---|
| Operating-temperature | -25°C ~ 100° C |
| Number of connection points | 3 |
| Max Cable Diameter | 12 mm |
| Min Cable Diameter | 4 mm |
| Total number of clamp positions | 3 |
| Core thickness | 0.5 - 2.5 mm² |
| Max Core thickness diameter | 2.5 mm |
| Min Core thickness diameter | 0.5 mm |
Color and material
| Color | Black |
|---|---|
| Material | Plastic |
Dimensions & weights
| Width | 100 mm |
|---|---|
| Height | 28 mm |
| Length | 105 mm |
General
| EAN | 8720365435096 |
|---|---|
| Brand | HOFTRONIC |
| Warranty | 2 year |
| Quantity | 5 |
| Certifications | CE, RoHs, TÜV |
| Warranty exemption | Not installed or used according to the manual |
Installation
| Ground wire | Yes |
|---|---|
| Connection voltage | 100-240V AC |
| Suitable for indoor outdoor | Indoor & outdoor |
Packaging
| Packaging type | Bag |
|---|---|
| Quantity mastercarton | 500 |
